PRO DESIGNED FOR TRAILBLAZERS AND 3D PRINTING EXPERTS
BLAZE A TRAIL
Explore the frontiers of 3D printing with a full-featured experimental 3D printer.
Be ready for the cutting-edge
Add a new level of creativity to your 3D designs with two interlaced colors that you can print through precisely aligned dual nozzles – without swapping or pausing
For MakerBot ABS Filament
Maker snaps, living hinges, threaded objects and more with a ductile, petroleum thermoplastic with elastic deformation properties. Control heating and cooling better with a superflat heated aluminum build plate and a clear, six-sided, draft-blocking enclosure that helps prevent uneven cooling, shrinking and cracking.
Speed your way to demonstrations and presentations with settings that range from fast-draft to finer resolution. Get smooth-to-the-touch surfaces that don’t need sanding, finishing or post-production.
SPEED YOUR WAY TO NEW DESIGNS
Accelerate the design process by prototyping right at your desk.
Quickly iterate to verify your designs and catch flaws sooner. Use your own physical models for collaboration and to bring better products to market, faster. Save money with the best price/performance in desktop 3D printing.
RELY ON SOPHISTICATED SOFTWARE
Get fast and consistent results.
MakerBot Desktop is optimized for the best quality printing experience on your MakerBot Replicator 2X. It’s powered by our advanced slicing engine, the algorithm that tells your MakerBot Replicator 2X what to make and how to make it.
|Print Technology||Fused Deposition Modeling|
|Build Volume||24.6 L x 15.2 W x 15.5 H cm [9.7 x 6.0 x 6.1 inch]|
|XY Positioning Precision||11 Microns [0.0004 inch]|
|Z Positioning Precision||2.5 Microns [0.0001 inch]|
|Filament Diameter||1.75mm [0.069 inch]|
|Nozzle Diameter||0.4mm [0.015 inch]|
|Software Bundle||MAKERBOT MAKERWARE|
|File Types||STL, OBJ, THING|
|Connectivity||USB, SD Card (Both Included)|
|Operating Systems||WINDOWS (7+), MAC OS X (10.6+), LINUX (UBUNTU 12.04+)|
|Chassis||Powder Coated Steel|
|Build Platform||Heated, black anodized 356F Aluminum|
|XYZ Bearings||Wear-resistant, oil-infused bronze|
|Stepper Motors||1.8° step angle with 1/16 micro-stepping|
|Storage Temperature||0.32°C [32°-90°F]|
|Operating Temperature||15°-32°c [60°-90°F]|
|AC Input||100-240V, ~4AMPS, 50-60 Hz|
|Power Requirements||24 V DC @ 9.2 Amps|
|Product Dimensions (Without Spool)||49 L x 32 W x 53.1 H cm [19.1 x 12.8 x 20.9 inch]|
|Product Dimensions (With Spool)||49 L x 42 W x 53.1 H cm [19.1 x 16.5 x 20.9 inch]|
|Shipping Dimensions||60.5 L x 58.4 W x 41.7 H cm [23 x 23.8 x 16.4 inch]|
|Product Weight||12.6 kg [27.8 lbs]|
|Shipping Weight||17.8 kg [39.25 lbs]|
